CJW4-TDLAS

Methane Multi parameter Instrument for Pipeline

Product description

It is a portable multi-parameter pipeline gas detection equipment. It is mainly used for the detection of methane gas concentration, pressure, temperature, and carbon monoxide concentration in extraction pipelines.

Message  Chat Online 

Related Products
Application

Product Description

CJW4 is a portable multi-parameter pipeline gas detection equipment. It is mainly used for the detection of methane gas concentration, pressure, temperature, and carbon monoxide concentration in extraction pipelines.

Feature

TDLAS technology
Measures all parameters simultaneously
Real-time data communication protocol supported
Fully compatible with IoT monitoring system
Battery level indication

Technical Parameter

Methane	(0.00~1.00)%CH4 ±0.05%CH4
	(1.00~100)%CH4 ±5% of true value
Absolute pressure	(10.~200.0)kPa ±0.75% FS
Temperature	(-20.0~+60.0) ℃ ±1.0℃
Carbon monoxide	(0.0~100) x10^-6 -4×10^-6
	(100~500)x10^-6 ±5% of true value
	(500~2000)x10^-6±6% of true value
